Universele de Thermistor Radiale PTC van 60V 72V 0.75A PolyTron PPTC Resettable Zekering TRC075 voor Automobieltoepassing

1000 stukjes
MOQ
0.03 to 0.05 USD Per Pieces
Prijs
Universele de Thermistor Radiale PTC van 60V 72V 0.75A PolyTron PPTC Resettable Zekering TRC075 voor Automobieltoepassing
Kenmerken Galerij Productomschrijving Verzoek om een Citaat
Kenmerken
Specificaties
Productnaam: PPTC-Thermistor Radiale PTC Resettable Zekering
Greepstroom: 0.75A
Nominale spanning: 60V/72V
Reisstroom: 1.50A
Maximale stroom: 40A
Max Trip Time: 6.3 seconde
Kracht: 0.9w
Vlam - vertragers epoxypolymeer isolerend materiaal: UL 94V-0
Markeren:

smd ptc resettable zekering

,

de positieve zekering van de temperatuurcoëfficiënt

Basis informatie
Certificering: UL,CSA,TUV,SGS
Modelnummer: TRC075
Betalen & Verzenden Algemene voorwaarden
Verpakking Details: Massa, 1000pcs per polybag
Levertijd: 10 werkdagen
Betalingscondities: T/T
Levering vermogen: 10.000.000 stukken per maand
Productomschrijving

Universele 60V 72V 0,75A PolyTron PPTC Thermistor Radial PTC Resettable Fuse TRC075 Voor automotive toepassing

Toepassing

• Medische apparatuur
• Witte goederen
• Industriële transmissie van energie
• Telecommunicatie
• Computers en randapparatuur
• Consumenten­ en automobiel­elektronica
• Oplaadbare batterijen

• Automobiele elektronica

De volgende categorieën zijn bedoeld:Universele de Thermistor Radiale PTC van 60V 72V 0.75A PolyTron PPTC Resettable Zekering TRC075 voor Automobieltoepassing 0 Download- Het is...

Productkenmerken

• PolyTronTM radial door-gat PTC-apparaat met lood

• Maximaal 60 volt,zelfs 72 volt

• Stroomvermogens van 0,05 tot 5 ampère

• Snelle reistijd

• Lage weerstand

• Halogeenvrij, loodvrij, RoHS-conform

Afmeting (mm)

Universele de Thermistor Radiale PTC van 60V 72V 0.75A PolyTron PPTC Resettable Zekering TRC075 voor Automobieltoepassing 1

V/N Een B. C D E Fysieke kenmerken
Max, ik ben er klaar voor. Max, ik ben er klaar voor. Typus. - Min. Max, ik ben er klaar voor. Stijl Lood Φ mm Materiaal
TRC005 7.4 12.7 5.1 7.6 3.1 1 0.51 CP
TRC010 7.4 12.7 5.1 7.6 3.1 1 0.51 CP
TRC017 7.4 12.7 5.1 7.6 3.1 1 0.51 CP
TRC020 7.4 12.7 5.1 7.6 3.1 1 0.51 CP
TRC025 7.4 12.7 5.1 7.6 3.1 1 0.51 CP
TRC030 7.4 13.4 5.1 7.6 3.1 1 0.51 CP
TRC040 9.7 14.5 5.1 7.6 3.1 1 0.51 CP
TRC050 9.7 15.2 5.1 7.6 3.1 1 0.61 C.
TRC065 9.7 15.2 5.1 7.6 3.1 1 0.61 C.
TRC075 10.4 16.0 5.1 7.6 3.1 1 0.61 C.
TRC090 11.7 16.7 5.1 7.6 3.1 1 0.61 C.
TRC110 13.0 18.0 5.1 7.6 3.1 2 0.81 C.
TRC135 14.5 19.6 5.1 7.6 3.1 2 0.81 C.
TRC160 16.3 21.3 5.1 7.6 3.1 2 0.81 C.
TRC185 17.8 22.9 5.1 7.6 3.1 2 0.81 C.
TRC250 21.3 26.4 10.2 7.6 3.1 2 0.81 C.
TRC300 24.9 30.0 10.2 7.6 3.1 2 0.81 C.
TRC375 28.4 33.5 10.2 7.6 3.1 2 0.81 C.
TRC500 28.4 33.5 10.2 7.6 3.1 2 0.81 C.

Elektrische prestaties

V/N (Ω)
IH, (A) IT,(A) Vmax, ((v) Imax, A. (A) (Sec.) PDtype ((W) Rmin Rmin R1max
TRC005 0.05 0.15 60 40 0.25 5.0 0.22 7.30 11.10 25.00
TRC010 0.10 0.20 60 40 0.50 4.0 0.38 2.30 8.10 12.0
TRC017 0.17 0.34 60/72 40 0.85 3.0 0.48 2.00 5.21 8.00
TRC020 0.20 0.40 60/72 40 1.00 2.2 0.40 1.30 2.84 4.50
TRC025 0.25 0.50 60/72 40 1.25 2.5 0.45 0.90 1.95 3.00
TRC030 0.30 0.60 60/72 40 1.50 3.0 0.50 0.70 1.36 2.10
TRC040 0.40 0.80 60/72 40 2.00 3.8 0.55 0.48 0.95 1.40
TRC050 0.50 1.00 60/72 40 2.50 4.0 0.75 0.38 0.78 1.20
TRC065 0.65 1.30 60/72 40 3.25 5.3 0.90 0.24 0.54 0.74
TRC075 0.75 1.50 60/72 40 3.75 6.3 0.90 0.23 0.45 0.62
TRC090 0.90 1.80 60/72 40 4.50 7.2 1.00 0.14 0.31 0.49
TRC110 1.10 2.20 60/72 40 5.50 8.2 1.50 0.15 0.25 0.40
TRC135 1.35 2.70 60/72 40 6.75 9.6 1.70 0.12 0.19 0.32
TRC160 1.60 3.20 60/72 40 8.00 11.4 1.90 0.09 0.14 0.24
TRC185 1.85 3.70 60/72 40 9.25 12.6 2.10 0.08 0.12 0.21
TRC250 2.50 5.00 60/72 40 12.50 15.6 2.50 0.05 0.08 0.15
TRC300 3.00 6.00 60/72 40 15.00 19.8 2.80 0.04 0.06 0.12
TRC375 3.75 7.50 60/72 40 18.75 24.0 3.20 0.03 0.05 0.10
TRC500 5.0 10.0 60/72 40 25.0 24.0 3.2 0.02 0.05 0.100

Aanbevolen profiel van de golfsoldeer.

Universele de Thermistor Radiale PTC van 60V 72V 0.75A PolyTron PPTC Resettable Zekering TRC075 voor Automobieltoepassing 2

Vermelding:

1. (1-3) °C/sec

2Ongeveer 200°C/sec

3.5°C/sec Maximaal

Milieuspecificaties

Kenmerkend Waarde
Werktemperatuurbereik -40°C tot +85°C
Oppervlaktetemperatuur 125°C max.
Thermische schok +85°C tot -40°C, 10 cycli, 5% typische weerstandsverandering
Resistentie tegen oplosmiddelen Mil-STD-202 methode 215, geen wijziging
Vochtigheidsleeftijdstest +85°C, 85% R.H., 1000 uur ±5% typische weerstandsverandering.
Temperatuurbereik voor opslag -10°C tot +40°C
Bewaartijd 12 maanden
Relatieve luchtvochtigheid -75%
Bewaringsvoorwaarden Bewaar uit de buurt van corrosieve atmosfeer en zonlicht

Aanbevolen bewerkingsomstandigheden met soldeer

• Temperatuur van het punt van het soldeer: maximaal 360°C.
• Soldeertijd: maximaal 3 seconden.
• Afstand van de thermistor: 2 mm min.

Thermische afnemingsgrafiek (ampere)

V/N Omgevingsoperatietemperatuur
-40°C -20°C 0°C 25°C 40°C 50°C 60°C 70°C 85°C
TRC005 0.08 0.07 0.06 0.05 0.04 0.04 0.03 0.03 0.02
TRC010 0.16 0.14 0.12 0.10 0.08 0.07 0.06 0.05 0.04
TRC017 0.26 0.23 0.20 0.17 0.14 0.12 0.11 0.09 0.07
TRC020 0.31 0.27 0.24 0.20 0.16 0.14 0.13 0.11 0.08
TRC025 0.39 0.34 0.30 0.25 0.20 0.18 0.16 0.14 0.10
TRC030 0.47 0.41 0.36 0.30 0.24 0.22 0.19 0.16 0.12
TRC040 0.62 0.54 0.48 0.40 0.32 0.29 0.25 0.22 0.16
TRC050 0.78 0.68 0.60 0.50 0.41 0.36 0.32 0.27 0.20
TRC065 1.01 0.88 0.77 0.65 0.53 0.47 0.41 0.35 0.26
TRC075 1.16 1.02 0.89 0.75 0.61 0.54 0.47 0.41 0.30
TRC090 1.40 1.22 1.07 0.90 0.73 0.65 0.57 0.49 0.36
TRC110 1.71 1.50 1.31 1.10 0.89 0.79 0.69 0.59 0.44
TRC135 2.09 1.84 1.61 1.35 1.09 0.97 0.85 0.73 0.54
TRC160 2.48 2.18 1.90 1.60 1.30 1.15 1.01 0.86 0.64
TRC185 2.87 2.52 2.20 1.85 1.50 1.33 1.17 1.00 0.74
TRC250 3.88 3.40 2.98 2.50 2.03 1.80 1.58 1.35 1.00
TRC300 4.65 4.08 3.57 3.00 2.43 2.16 1.89 1.62 1.20
TRC375 5.81 5.10 4.46 3.75 3.04 2.70 2.36 2.03 1.50
TRC500 7.75 6.80 5.95 5.00 4.05 3.60 3.15 2.71 2.00
Pakketinformatie

Model Qty/zak

TRC005-TRC0901000 stuks

TRC110-TRC185500 stuks

TRC250-TRC500200 stuks
